Layout basics - what fits where
The first decision is the shape. In a 10-12 sq m cabin you'll usually end up with L-shape or parallel. In a 20 sq m townhouse an island becomes viable. Below are the practical dimensions we keep in mind.
| Layout | Recommended minimum width | Recommended minimum length | Typical use case |
|---|---|---|---|
| L-shape | 2.4 m | 3.0 m | 1-bed flats, small villas |
| U-shape | 2.4 m | 3.6 m | medium size homes, families of 4-5 |
| Parallel | 2.4 m | 2.4 m | narrow corridor kitchens, open-plan dining |
| Island | 2.0 m clearance around island | 1.2 m width (standard) | large plan, entertaining spaces |
A rule of thumb: keep the "work triangle" (sink-stove-fridge) under 4 m total. Anything longer feels like a marathon every time you cook.
Cabinet face material - acrylic, laminate, PU, membrane, veneer
Acrylic gives a glossy, easy-clean finish but scratches easily. Laminate is cheap, wide colour range, but edges can chip. PU (polyurethane) offers a matte look and decent durability; we see it in mid-range projects. Thermoplastic membrane (PVC-based) is moisture-resistant, good for humid kitchens. Veneer looks like real wood but needs careful sealing.
| Material | Durability (years) | Water resistance | Cost per sq ft (Rs.) | Typical brands |
|---|---|---|---|---|
| Acrylic | 5-7 | Medium | 350-500 | Sleek, Godrej Interio |
| Laminate | 4-6 | Low | 250-350 | IKEA India, Livspace |
| PU | 6-8 | Medium | 300-450 | Kitchen Magic, Bonito Designs |
| Membrane | 5-7 | High | 280-400 | HomeLane, Ebco |
| Veneer | 7-10 | Medium | 400-600 | Häfele, Blum |
If you live in a monsoon-prone area, go for membrane or a high-gloss acrylic with a water-proof seal. For a sleek city apartment, matte PU looks professional without the glare of acrylic.
Core options - BWP, BWR, HDHMR, MDF, plywood
The core decides how the cabinet holds up over time. BWP (Boiling Water Proof) and BWR (Boiling Water Resistant) are particle-board blends with resin. They survive occasional splashes but swell if water sits. HDHMR (High Density High Moisture Resistant) is a step up - we use it for budget ranges where the client wants a light look. MDF is dense, smooth, but hates moisture. Marine-grade plywood (15 mm) is the gold standard for premium kitchens; it resists warping and can bear heavy hardware.
| Core | Thickness (mm) | Moisture rating | Cost per sq ft (Rs.) | Best for |
|---|---|---|---|---|
| BWP | 16 | Medium | 120-150 | Budget L-shape |
| BWR | 18 | Medium-High | 150-180 | Mid-range parallel |
| HDHMR | 16 | High | 180-210 | Small U-shape |
| MDF | 19 | Low | 200-240 | Cabinets with thin veneers |
| Plywood (Marine) | 15-18 | Very High | 250-300 | Island, heavy hardware |
When I see a client ask for "cheap but looks like wood", I warn them: veneer on BWP will delaminate within two years. A small extra on plywood saves a lot of repair cost later.
Cost breakdown - budget, mid, premium per sq ft
We calculate everything on a per-sq-ft basis, then multiply by the cabinet area (usually 30-35 sq ft for a 10 sq m kitchen).
| Tier | Cabinet material + core (Rs.) | Hardware (Rs.) | Countertop (Rs.) | Total per sq ft (Rs.) |
|---|---|---|---|---|
| Budget | 400 | 150 | 800 (laminate granite) | 1,350 |
| Mid | 650 | 250 | 1,500 (engineered quartz) | 2,400 |
| Premium | 950 | 400 | 2,800 (natural quartz or Corian) | 4,150 |
A 12 sq ft cabinet area in a 10 sq m kitchen will cost roughly Rs. 16,200 (budget), Rs. 28,800 (mid) or Rs. 49,800 (premium). Add Rs. 30,000-50,000 for island fittings if you have space.
Hardware - hinges, drawer slides, handles
Hardware makes or breaks the feel. I trust German-engineered slides (Blum, Häfele) for heavy pots; they glide for years. Indian brands like Ebco and Kitchen Magic give decent soft-close at half the price but wear out faster.
| Brand | Slide type | Price range per pair (Rs.) | Warranty |
|---|---|---|---|
| Blum | Clip-top soft-close | 2,500-3,500 | 10 years |
| Häfele | Full-extension soft-close | 2,200-3,200 | 8 years |
| Ebco | Side-mount soft-close | 1,200-1,800 | 5 years |
| Kitchen Magic | Side-mount basic | 800-1,200 | 3 years |
| Godrej Interio | Clip-top basic | 1,000-1,500 | 5 years |
For island cabinets that bear a lot of weight, go for full-extension slides; side-mount will sag under 15 kg loads.
Workflow triangle - keep it tight
- Place the sink between the fridge and the stove, not at an extreme corner.
- Maintain a clearance of at least 1.2 m between any two work points.
- Use a pull-out pantry or corner carousel to keep the triangle clear.
- Position the dishwasher (if any) next to the sink for easy rack loading.
If the triangle exceeds 4 m, you'll notice the fatigue after a few dishes. Adjust cabinet heights (90 cm standard) to suit the user's elbow level.
Chimney selection and ducting
A chimney's suction rating must match the cooking style. Indian families that fry heavy (pakoras, samosas) need at least 1200 m3/h. For a 3-burner gas stove, 1000 m3/h is the minimum. Stainless steel baffles are a must; copper baffles rust faster in coastal areas.
Duct length matters. Every 2 m of duct adds about 10% resistance. Use a 4-inch insulated duct for low-rise apartments; for villas, a 6-inch duct reduces noise.
Related: Kitchen Chimney Buying Guide 2026 - Types, Sizes, Suction Power and Installation for Indian Homes
Countertop choices - granite, quartz, Corian, marble, stainless steel
Granite stays popular because it tolerates high heat. Indian black granite runs Rs. 1,200-1,500 per sq ft, while polished grey is Rs. 900-1,100. Engineered quartz offers uniform colour, low porosity. Prices are Rs. 1,800-2,200 per sq ft for 12 mm thickness. Corian (solid surface) is Rs. 2,000-2,500; it can be sanded and resealed. Marble looks elegant but stains; local Makrana marble is Rs. 1,100-1,400 per sq ft. Stainless steel 1 mm sheet is Rs. 1,500-1,800 per sq ft and gives a professional look for a small bar area.
| Material | Heat resistance | Stain resistance | Cost per sq ft (Rs.) | Best use |
|---|---|---|---|---|
| Granite | High | Medium | 900-1,500 | Standard cooking area |
| Quartz | Medium | High | 1,800-2,200 | High-end, uniform colour |
| Corian | Medium | Very High | 2,000-2,500 | Sink integrated, seamless |
| Marble | Low | Low | 1,100-1,400 | Accent or bar top |
| Stainless steel | Very High | Very High | 1,500-1,800 | Commercial look, small prep zone |
My rule: never use marble near the stove. It cracks under thermal shock.
Lighting - task, ambient, accent
Task lighting directly over the sink and stove should be 300-500 lux. LED strip lights under upper cabinets give a clean ambient glow and cost Rs. 80-120 per foot. Accent downlights on the island perimeter add drama; a 6-Watt dimmable LED costs Rs. 350 each.
Place a warm-white (3000 K) LED above the dining side, and a cool-white (4000 K) over the prep zone. Mixing colour temperatures confuses the eye.
Ventilation and electrical planning
Every major appliance needs its own circuit. A 6 kW induction cooktop draws 30 A; give it a dedicated 32 A breaker. The fridge, microwave, and dishwasher each need a 6 A line. Run the wires in a concealed conduit under the countertop, not in the ceiling plaster.
Ventilation isn't just the chimney. Provide at least two 15 cm exhaust vents in the wall if the chimney is wall-mounted, or a roof vent with a back-draft damper for island hoods.
Modular vs semi-modular vs carpenter-built
| Option | Lead time | Cost per sq ft (Rs.) | Flexibility | Typical warranty |
|---|---|---|---|---|
| Modular (ready-made) | 2-4 weeks | 1,200-1,800 | Low - fixed dimensions | 5 years |
| Semi-modular (custom panels) | 4-6 weeks | 1,500-2,400 | Medium - can change heights | 7 years |
| Carpenter-built | 6-10 weeks | 1,800-3,000 | High - fully bespoke | 10 years |
If the layout is standard (L or parallel) and the budget is tight, modular wins. For a U-shape island with irregular ceiling height, I recommend semi-modular; it lets you tweak cabinet heights without a full custom job.
Common mistakes - what I see on site
- Choosing glossy acrylic for a humid kitchen - it fogs and shows water marks.
- Installing a 90 cm high countertop for a 5-ft tall user - constant back-bending.
- Using MDF core in a coastal city - it swells within months.
- Placing the chimney too far from the stove - loss of suction, more smoke.
- Ignoring the workflow triangle - you end up walking around the kitchen.
- Underspecifying electrical load - breaker trips when the oven and microwave run together.
- Skipping a dedicated pantry - you'll crowd the cabinets with jars.
- Relying on cheap hardware for heavy drawers - slides sag and break.
Checklist before you sign the contract
- Confirm layout dimensions on site with a tape measure.
- Choose core material based on moisture exposure.
- Select face material that matches daily use (acrylic for sleek look, membrane for wet zones).
- Verify hardware brand, slide type, and warranty.
- Ensure chimney suction rating >= 1200 m3/h for Indian cooking.
- Get a detailed electrical plan with separate breakers.
- Ask for a mock-up of the work triangle - walk through it.
- Check that the countertop supplier provides a 2-year stain warranty.
Final take - what I recommend for a 12 sq m 3-BHK kitchen
Go L-shape, 2.4 m by 3.0 m, with a 90 cm countertop. Use membrane face on BWR core for the lower cabinets - it survives splashes and costs about Rs. 330 per sq ft. Upper cabinets in PU on HDHMR give a matte look and stay under Rs. 400 per sq ft. Choose a 12 mm engineered quartz slab at Rs. 2,000 per sq ft; the extra cost pays off in low maintenance. Fit a 1300 mm wall-mounted chimney with 1300 m3/h suction and a 4-inch insulated duct. Install Blum full-extension slides for the island drawers, and Hettich soft-close hinges for the doors. Wire a dedicated 32 A breaker for the induction hob, a 16 A line for the fridge, and a 10 A line for the microwave. Finish with LED strips under the cabinets and a couple of downlights over the island.
That set-up stays under Rs. 2.5 lac total, gives a smooth workflow, and will look good for at least a decade. If you have the space for an island, add a 1.2 m wide island with a stainless steel prep top - it raises the cost by Rs. 50,000 but adds a real social hub.
